BS Series Venting Membrane

BS Series Venting Membrane

Waterproof, dustproof, and breathable, balancing internal and external pressure differences in sealed enclosures.

Advantages

FUTUREWAY® BS Series Venting Membrane can rapidly adjust to environmental pressure changes, featuring high tensile strength and durability, as well as excellent weldability, ensuring the structure's robustness and stability.

Pressure Balancing

Rapidly equalizes pressure gradients caused by environmental changes.

Stable Performance

Excellent chemical compatibility and thermal stability.

Dust and Oil Proof

Effectively blocks dust particles, salt spray, and other contaminants.

BS Series Venting Membrane

Applications

  • Small battery packs
  • Radars, sensors, motors, etc
  • Automotive and motorcycle lighting systems

Series

  • Product
  • Colour
  • Parameter
  • Characteristic
  • Download
  • BS-06
  • White
  • Air flux: 450ml/min/c㎡@7kPa; Water resistance pressure: >35kPa,60s@Φ10mm, IP68*
  • High air permeability, acid and alkali resistance and chemical inertness
  • Download
  • BS-08R
  • White
  • Air flux: 200ml/min/c㎡@7kPa; Water resistance pressure: >80kPa,60s@Φ10mm, IP68*
  • High water resistance, acid and alkali resistance and chemical inertness
  • Download
  • BS-07AL
  • Black
  • Air flux: 900ml/min/c㎡@7kPa; Water resistance pressure: >40kPa,60s@Φ10mm, IP68*; MVTR: 2300g/m²/day
  • High moisture transmission, acid and alkali resistance and chemical inertness
  • Download
  • BS-08AL
  • Black
  • Air flux: 360ml/min/c㎡@7kPa; Water resistance pressure: >60kPa,60s@Φ10mm, IP68*; MVTR: 1600g/m²/day
  • High moisture transmission, acid and alkali resistance and chemical inertness
  • Download
