Thermal Insulation Silicone Foams

Thermal Insulation Silicone Foams

Combines thermal insulation and cushioning, ensuring advanced protection for prismatic and pouch cell batteries.

Advantages

FUTUREWAY® Thermal Insulation Silicone Foam is a silicone material with ultra-high temperature thermal insulation function with a new silicone technology. At the low temperature (<200C), Thermal Insulation Silicone Foam has excellent resilience, flexibility, compressibility and ultra-low density so that it has the functions of cushioning, thermal preservation and absorbing structural tolerances. At the ultra-high temperature (>600C), it can inhibit heat diffusion,isolate high temperature to protect sensitive structures.

Exceptional thermal insulation

Excellent thermal insulation performance under high temperature (>600℃) environment.

Flame Retardant

Meets UL 94 V-0 flame resistance requirements.

Wide Compression Stress Range

Adapts to structural and assembly tolerances, stable across varying compression stresses.


Thermal Insulation Silicone Foams

Applications

  • Buffer and thermal insulation pad between pouch cells
  • Module insulation pad
  • The thermal pad between the PACK and the car body

Series

  • Product
  • Colour
  • Parameter
  • Characteristic
  • Download
  • TIF-15
  • Black
  • Density: 430kg/m³; Compression stress (25%): 157kPa; Thermal Insulation(600˚C @ 5 min): 140(2mmT)
  • Integrates insulation and cushioning, ideal for thermal buffering in prismatic cell applications.
  • Download
  • TIF-25
  • Black
  • Density: 330kg/m³; Compression stress (25%): 67kPa; Thermal Insulation(600˚C @ 5 min): 140(2mmT)
  • Integrates insulation and cushioning, ideal for thermal buffering in pouch cell applications
  • Download
